Objects and Tables

• Moving complex data from SQL to PHP is troublesome

• OOP fundamentally different from relational algebra

• Evolved data-source patterns to deal with this

Data Source Architecture

• Row Data Gateway: row data and peristence logic

• Active Record: row data, persistence logic, and domain logic

• Table Data Gateway: all table rows, and persistence logic

• Data Mapper: persistence logic for a disconnected domain object

Domain Logic

• Domain "should not" be modeled on database structure

• Keep domain objects separated from database connections

• Converting between database and domain is very difficult

• "Object-Relational Impedance Mismatch"

ORMs

• Ease conversion of relational rows to domain objects

• Generate SQL, retrieve/save data, map data to objects

• Active Record (persistence combined with domain logic)

• Data Mapper (persistence separated from domain objects)

Tradeoffs (Active Record)

• Easy to start with for CRUD/BREAD

• Easy to add simple domain logic

• As complexity increases, need separate domain layer

• Hard to extract domain behavior from perisistence

• Harder to maintain and refactor

Tradeoffs (Data Mapper)

• Clear separation between persistence and domain

• Easier to maintain as complexity increases

• Harder to get started with

• Presumes rich domain model and mapping expertise

• Too much for early CRUD/BREAD operations

The Underlying Problem

• All systems start simple

• Some systems become complex

• Can't tell in advance

• Want a low-cost path in case of complexity

Desiderata

• Easy to get started with

• Clear refactoring path if complexity increases

• Amenable to CRUD/BREAD in early stages

• Ability to add simple behaviors

• Strategy to convert from ORM to Domain Model proper

• Maintain separation of persistence from data

Persistence Model, not Domain Model

• Use the Data Mapper approach for separation

• Instead of mapping to domain model entities (Aggregates) ...

• ... map to the persistence model rows and relationships (Records)

Atlas

• A data mapper for your persistence model

• Build a series of Table Data Gateway

• Relate them to each other via Mappers

• Retrieve and save Record objects through the Mapper objects

Mapper Object

<?php
namespace App\DataSource\Thread;
use App\DataSource\Author\AuthorMapper;
use App\DataSource\Summary\SummaryMapper;
use App\DataSource\Reply\ReplyMapper;
use App\DataSource\Tagging\TaggingMapper;
use App\DataSource\Tag\TagMapper;
use Atlas\Orm\Mapper\AbstractMapper;
class ThreadMapper extends AbstractMapper
{
    protected function setRelated()
    {
        $this->manyToOne('author', AuthorMapper::CLASS);
        $this->oneToOne('summary', SummaryMapper::CLASS);
        $this->oneToMany('replies', ReplyMapper::CLASS);
        $this->oneToMany('taggings', TaggingMapper::CLASS);
        $this->manyToMany('tags', TagMapper::CLASS, 'taggings');
    }
}

Atlas Container

<?php
$container = new \Atlas\Orm\AtlasContainer(
    'mysql:dbname=testdb;host=localhost',
    'username',
    'password'
);
$container->setMappers(
    \App\DataSource\Author\AuthorMapper::CLASS,
    \App\DataSource\Summary\SummaryMapper::CLASS,
    \App\DataSource\Reply\ReplyMapper::CLASS,
    \App\DataSource\Thread\ThreadMapper::CLASS,
    \App\DataSource\Tagging\TaggingMapper::CLASS,
    \App\DataSource\Tag\TagMapper::CLASS,
);
$atlas = $container->newAtlas();

CRUD/BREAD Retrieval with Relatonships

$threads = $atlas->select(ThreadMapper::CLASS)
    ->limit(10)
    ->orderBy(['date DESC'])
    ->with([
        'author',
        'replies' => function ($replies) {
            $replies
                ->orderBy(['date ASC'])
                ->with(['author']);
        };
        'taggings',
        'tags',
    ])
    ->fetchRecordSet();
foreach ($threads as $thread) {
    echo "{$thread->title} by {$thread->author->first_name} "
        . "has " count($thread->replies) . " replies.";
}

CRUD/BREAD Saving

$thread = $atlas->newRecord(ThreadMapper::CLASS);
$thread->title = 'New Title';
$atlas->insert($thread);
echo $thread->thread_id;
$thread = $atlas->fetchRecord(ThreadMapper::CLASS, $threadId);
$thread->title = 'Changed Title';
$atlas->update($thread);
$thread = $atlas->fetchRecord(ThreadMapper::CLASS, $threadId);
$atlas->delete($thread);

Adding Simple Behaviors

<?php
namespace App\DataSource\Author;
use Atlas\Orm\Mapper\Record;
class AuthorRecord extends Record
{
    public function getFullName()
    {
        return $this->first_name . ' ' . $this->last_name;
    }
}

Richer Domain Models

<?php
namespace App\Domain\Thread;
use App\DataSource\Thread\ThreadMapper;
class ThreadRepository
{
    protected $mapper;
    public function __construct(ThreadMapper $mapper)
    {
        $this->mapper = $mapper;
    }
    public function fetchThread($thread_id)
    {
        $record = $this->mapper->fetchRecord(...);
        return $this->newThread($record);
    }
    protected function newThread(ThreadRecord $record)
    {
        /* ??? */
    }
}

Compose Persistence Into Domain

class ThreadRepository
{
    protected function newThread(ThreadRecord $record)
    {
        return new ThreadAggregate($record);
    }
}

Map From Persistence To Domain

class ThreadRepository
{
    protected function newThread(ThreadRecord $record)
    {
        return new ThreadAggregate(
            $record->thread_id,
            $record->title,
            $record->body,
            $record->date_published,
            $record->author->author_id,
            $record->author->name,
            $record->tags->getArrayCopy(),
            $record->replies->getArrayCopy()
        );
    }
}
